Widely used in the aerospace, aviation, military, armed police, public security, customs, security, monitoring, petroleum, chemical, electric power and other industries.
Widely used in the aerospace, aviation, military, armed police, public security, customs, security, monitoring, petroleum, chemical, electric power and other industries.
Main control functions： Manual background correction, manual shutter correction, BH/WH polarity setting, 2×E-zoom, 4×E-zoom, cross reticle display, image gain adjustment, image brightness adjustment, cross reticle position adjustment, image enhancement, electronic focus control, electronic zoom control, system parameter rest, etc.
Technical Specification
| DETECTOR | |
| Detector | Uncooled FPA |
| Pixel | 640×480 |
| Pitch | 17μm |
| Spectral Band | 8μm~12μm |
| Start Time | ≤30s |
| NETD | ≤50mk(F/1) |
| Cooling Down | ≤12s |
| FUNCTION INTERFACE | |
| Video Output | 1way analog video output, PAL format 1 way LVDS digital video output Automatic external synchronization function(input 3.3VTTL,20ms square wave) |
| Communication | RS232 / RS422 serial port(not used at the same time ) |
| Working temperature | -40℃ ~ +60℃ |
| Storage temperature | -50℃ ~ +70℃ |
| Power Supply | DC 7V~24V |
| Consumption | ≤ 1.8W@25ºC steady state |
| Weight | ≤ 65g (connector not included) |
